copy of Pantograph scissor lift

€21,780.00
Tax included
€18,000.00 Tax excluded

Scissor lifts are recommended for use in steering alignments, vehicle testing, maintenance and maintenance of different types of small cars.

…

+ More info
10/EQT-S7.5T-380
0
Este producto no está disponible para el envío ordinario, contacte con nosotros para solicitar una cotización personalizada de su envío.
Abrir formulario de contacto
close

Cotización de transporte



Scissor lifts are recommended for use in steering alignments, vehicle testing, maintenance and maintenance of different types of small cars.

FUNCTIONS AND CHARACTERISTICS OF THE EQUIPMENT:


• Independent control box. The low voltage controls (24V) provide great safety.
• Pleasant appearance, with concealable structure for both levels, reducing the space required.
• Volumetric-hydraulic cylinder synchronization.
• Optimized for assembly and disassembly, as well as maintenance of the vehicle chassis.
• The position of the turntable of the front wheel is mobile, so the turntable can be adapted to more cars.
• Double mechanical safety ratchet.
• Safety valve for hydraulic failure or overload
• Kick-off device and shut-off valve for cases of rupture or explosion in cylinder or piping.
• Level control with integrated photocell device
• Mechanism and alarm for the complete lowering of the platforms.
• Emergency device for the descent of the platforms in case of electric failure.



The car lift is provided without any liquid.



TECHNICAL CHARACTERISTICS:

Feeding

AC 400 o 230V 65/50HZ

Power

2.2 Kw

Load capacity main unit

4.500 Kg

Secondary load capacity

4.500 Kg

Type of system

Eléctrico hidráulico

Lifting height main unit

1.850 mm

Lifting height secondary unit

450 mm

Platform Height

330 mm

Length of main unit

5.030 mm

Length of secondary unit

1.630 mm

Width of main unit

620 mm

Width of secondary unit

550 mm

Total length

5.510 mm
Overall Width

2.800 mm

Rise time main unit

<50 s

Down time main unit

>60 s

Secondary unit upload time

<20 s

Secondary unit down time

>30 s

Noise level

≤ 76 db(A)

Weight

2.800 Kg


REQUIREMENTS
The installation of this equipment should be in a perfectly level.

NOTE
The customer agrees to dispose of the material appropriate for the download of this special machinery safely.

Not responsible for reservations to the download you can have the carrier.

DELIVERY CARRIER SUBJECT TO AVAILABILITY
